Diesel Engine Main Specification:

Rated power: 210~600kW（285~816 HP）

Engine Type:  Four  stroke,  Direct injection, Turbocharged, Intercooled

Cyl. No: In line 6/8

Bore×Stroke : 170×200mm

Engine Rev:  1000~1500rpm

Compression Ratio: 14.5:1

Mean effective pressure: 8.27~15.8bar

Fuel consumption rate: 196+3%g/kW·h

Lube  oil consumption rate: ≤0.7 g/kW·h

NOx Emission: IMO Tier II

Piston lifting height: 1260 mm above crankshaft centerline
