Diesel Engine Main Specification:

Rated power: 735~3089kW（1000~4200 HP）

Engine Type:  Four  stroke,  Direct injection, Turbocharged, Intercooled

Cyl. No: In line 6/8

Bore×Stroke : 320×380mm

Engine Rev:  550~650 rpm

Compression Rate: 13:1

Mean effective pressure: 8~23.3bar

Fuel consumption ratio: 195+5%g/kW·h

Lube  oil consumption rate:  ≤0.8 g/kW·h

NOx Emission: IMO Tier II

Piston lifting height: 2600 mm above crankshaft centerline
