Diesel Engine Main Specification:

Rated power: 374~1470kW（508~2000 HP）

Engine Type:  Four  stroke,  Direct injection, Turbocharged, Intercooled

Cyl. No: In line 6/8

Bore×Stroke : 210×300mm

Engine Rev:  600~1000rpm

Compression Ratio: 15:1

Mean effective pressure: 12.0~21.23bar

Fuel consumption rate: 194+5%g/kW·h

Lube  oil consumption rate:  ≤0.8 g/kW·h

NOx Emission: IMO Tier II

Piston lifting height: 1650 mm above crankshaft centerline
