Diesel Engine Main Specification:

Rated power: 1103~3089kW（1500~4200 HP）

Engine Type:  Four  stroke,  Direct injection, Turbocharged, Intercooled

Cyl. No: In line 6/8

Bore×Stroke : 300×380mm

Engine Rev: 500~750 rpm

Compression Rate: 13.5:1

Mean effective pressure: 16.4~23.0bar

Fuel consumption ratio: 194+5%g/kW·h

Lube  oil consumption rate: ≤0.8 g/kW·h

NOx Emission: IMO Tier II

Piston lifting height: 2600 mm above crankshaft centerline
