Diesel Engine Main Specification:

Rated power: 551~2427kW（750~3300 HP）

Engine Type:  Four  stroke,  Direct injection, Turbocharged, Intercooled

Cyl. No: In line 6/8

Bore×Stroke : 300×380mm

Engine Rev:  428~750rpm

Compression Ratio: 13:1

Mean effective pressure: 11.0~21.9bar

Fuel consumption rate: 195+5%g/kW·h

Lube  oil consumption rate: ≤0.8 g/kW·h

NOx Emission: IMO Tier II

Piston lifting height: 2600 mm above crankshaft centerline
