Diesel Engine Main Specification:

Rated power: 2648~3310kW（3600~4500 HP）

Engine Type:  Four  stroke,  Direct injection, Turbocharged, Intercooled

Cyl. No: In line 8

Bore×Stroke : 320×380mm

Engine Rev:  600~675 rpm

Compression Rate: 13:1

Mean effective pressure:  21.7~24.1bar

Fuel consumption ratio: 195+5%g/kW·h

Lube  oil consumption rate: ≤0.8 g/kW·h

NOx Emission: IMO Tier II

Piston lifting height: 2600 mm above crankshaft centerline
