Diesel Engine Main Specification:

Rated power: 2206~4045kW（3000~5500 HP）

Engine Type:  Four  stroke,  Direct injection, Turbocharged, Intercooled

Cyl. No: In line 6/8

Bore×Stroke : 330×450mm

Engine Rev: 550~650 rpm

Compression Rate: 13.5:1

Mean effective pressure: 18.5~24.3bar

Fuel consumption ratio: 184+3%g/kW·h

Lube  oil consumption rate:  ≤0.6 g/kW·h

 IMO Tier II

Piston lifting height: 2400 mm above crankshaft centerline
