Diesel Engine Main Specificaion

Rated power: 220~600kW（300~816 HP）

Engine type: Four Stroke, Direct Injection, Turbocharged, Intercooled

Cyl. No.: In line 6/8

Bore × Stroke: 170×200mm

Engine Rev. 1000~1500rpm

Compression ratio: 14.5:1

Mean effective pressure: 9.2~15.6bar

Diesel consumption rate: 196+3%g/kW·h

Gas consumption rate: 8600kJ/ kW·h（at rated power）

Lube oil consumption rate: ≤0.6 g/kW·h

Gas supply power: 4~6bar

Substitution rate: 70~85%（ata 50%~85% rated power）

NOx emission: IMO Tier II

Piston lifting height: 1260mm above crankshaft centerline
