Diesel Engine Main Specification

Rated power: 1323~2648kW（1800~3600 HP）

Engine type: Four stroke, Direct injection, Turbocharged, Intercooled

Cyl. No.: In line 6/8

Bore × stroke: 320×380mm

Engine Rev.: 550~650rpm

Compression Ratio: 13:1

Mean effective pressure: 14.4~22.8bar

Diesel consumption Rate: 195+5%g/kW·h

Gas consumption rate: 8600kJ/ kW·h（at rated power）

Lube oil consumption rate:≤0.6 g/kW·h

Gas supply pressure: 4~6bar

Substitution rate: 70~85%（at 50%~85% rated power）

NOx Emission: IMO Tier II

Piston lifting height: 2400mm above crankshaft centerline
