Diesel Engine Main Specification

Rated power: 551~2206kW（750~3000 HP）

Engine Type: Four stroke, Direct injection, Turbocharged, Intercooled

Cyl. No.: In line 6/8

Bore×Stroke: 300x380mm

Engine Rev.: 400~750rpm

Compression Ratio: 13.5:1

Mean effective pressure: 10.2~16.4bar

Diesel consumption rate: 195+5%g/kW·h

Gas consumption rate: 8600kJ/ kW·h（at rated power）

Lube oil consumption rate: ≤0.6 g/kW·h

Gas supply pressure: 4~6bar

Substitution rate: 70~85%（at 50%~85% rated power）

NOx Emission: IMO Tier II

Piston lifting height: 2600mm above crankshaft
