Diesel Engine Main Specification

Rated power: 396~1200kW（538~1632 HP）

Engine Type: Four stroke, Direct injection, Turbocharged, Intercooled

Cyl. No.: In line 6/8

Bore × Stroke: 210x300mm

Engine Rev.: 600~1000rpm

Compression rate: 15:1

Mean effective pressure: 12~17.3bar

Diesel consumption rate: 194+5%g/kW·h

Gas consumption rate: 8600kJ/ kW·h（at rated power）

Lube oil consumption rate: ≤0.6 g/kW·h

Gas supply pressure: 4~6bar

Substitution rate: 70~85%（at 50%~85% rated power ）

NOx emission: IMO Tier II

Piston lifting height: 1650mm above crankshaft centerline
