Diesel Engine Main Specification:

Rated power: 3310~3600kW （4500~4896 HP）

Engine Type:  Four  stroke,  Direct injection, Turbocharged, Intercooled

Cyl. No: In line 6/8

Bore×Stroke : 340×450mm

Engine Rev: 600~650rpm

Compression Ratio: 13.5:1

Mean effective pressure: 20.3~20.7bar

Diesel consumption rate: 186+5%g/kW·h

Gas consumption rate: 8600kJ/ kW·h (at rated power)

Lube  oil consumption rate: ≤0.6 g/kW·h

Gas supply pressure: 4~6bar

Substitution rate: 70~85%（at 50%~85% rated power）

NOx Emission: IMO Tier II

Piston lifting height: 2400 mm above crankshaft centerline
