Diesel Engine Main Specification:

Rated power: 2000~3500kW

Engine Type:  Four  stroke,  Direct injection, Turbocharged, Intercooled

Cyl. No: In line 6/8

Bore×Stroke : 330×450/340×450mm

Engine Rev:  600 rpm

Compression Ratio: 13:1

Diesel consumption rate: 186+5%g/kW·h

Gas consumption rate: 8600kJ/ kW·h (at rated power)

Lube  oil consumption rate: ≤0.6 g/kW·h

Gas supply pressure: 4~6bar

Substitution rate: 70~85%（at 50%~85% rated power）

NOx Emission: IMO Tier II

Piston lifting height: 2400 mm above crankshaft centerline
