Diesel Engine Main Specification:

Rated power: 200~500kW

Engine Type:  Four  stroke,  Direct injection, Turbocharged, Intercooled

Cyl. No: In line 6/8

Bore×Stroke : 170×200mm

Engine Rev: 1000~1500 rpm

Compression Ratio: 14.5:1

Diesel consumption rate: 196+3%g/kW·h

Gas consumption rate: 8600kJ/ kW·h (at rated power)

Lube  oil consumption rate: ≤0.6 g/kW·h

Gas supply pressure: 4~6bar

Substitution rate: 70~85%（at 50%~85% rated power）

NOx Emission: IMO Tier II

Piston lifting height: 1260 mm above crankshaft centerline
