Diesel Engine Main Specification:

Rated power: 551~1200kW（750~1632 HP）

Engine Type:  Four  stroke,  Direct injection, Turbocharged,  Water Cooling, Intake manifold Multi-point Fuel Injection

Cyl. No: In line 8

Bore×Stroke : 210×300mm

Engine Rev:  750~1000rpm

Compression Rate: 12.5:1

Mean effective pressure: 14.1~17.4bar

Engine thermal efficiency: 41.5%

NOx Emission: IMO Tier Ⅲ

Piston lifting height: 1650 mm above crankshaft centerline
